Prototyping in just one day
Intuitive CircuitPro software included
Supports up to eight PCB layers
Efficient PCB fabrication using mechanical systems
At Tracks Laser & Electronics Ltd, we use mechanical and laser-based systems to create single-sided, double-sided, and multilayer PCBs with precision and speed. These systems allow us to produce high-capacity circuits, RF and microwave boards, and both rigid and flexible PCB structures. By removing copper layers in controlled patterns, we form accurate conductive paths and insulating channels, while also completing all required drilling operations within a streamlined prototyping workflow.
Copper removal and circuit definition process
-
Copper layers are selectively removed from single- and double-sided boards
-
Insulating channels are created to define precise conductive traces and pads
-
Circuit board plotters are used to drill all required through-holes
-
Mechanical and laser structuring support multilayer PCB production
-
Standard prototype milling can be completed in around 30 minutes
-
The process supports RF, microwave, rigid, and flex PCB designs
-
LPKF Laser & Electronics systems ensure accuracy across all structuring steps
High-precision laser structuring
Laser structuring allows us to form conductive paths with higher speed and accuracy compared with mechanical methods. At Tracks Laser & Electronics Ltd, we use this approach to create precise geometries on a wide range of substrates, including copper-clad FR4, aluminised PET film, ceramics, Duroid, and PTFE.
Combined with clear process steps and software with intuitive operation, this flexibility enables us to handle demanding electronic applications while maintaining consistency, repeatability, and controlled fabrication outcomes across different PCB prototyping requirements.
Speed up your PCB prototyping
Call us today for PCB structuring and prototyping support.
